Emulator Adblue camion MAN EURO6 model 2023 calitate superioara !

Descriere

Emulator Adblue pentru MAN TGX Euro 6.

!!! Atentie: Nu ne asumam raspunderea pentru utilizarea acestor dispozitive, in Romania precum si unele tari Europe este INTERZISA folosirea acestor aparate !!!
Acest emulator ptr Man Euro 6 nu necesita programare. Tot ce trebuie sa faceti este sa scoateti conectorul de la unitatea de Adblue situata in partea spate dreapta a cabinei si sa cuplati acest emulator.

Trebuiesc scoase urmatoarele trei sigurante din tablou:

F894(Multisensor In AdBlue tank)

F738 (+30 Signal of AdBlue pump)

F1084(NOx sensor Upstream)

Fuse F737 devine siguranta ptr emulator

Siguranta F1109 este siguranta ptr senzorul de noxe NOx
Siguranta A1191 este siguranta pentru senzorul de temperatura. Acest senzor trebuie sa functioneze ptr regenerarea filtrului de particule.
Ultimul lucru care trebuie facut este sa deconectam alimentarea senzorului de noxe. Acest lucru se poate face prin doua metode:
var 1. se scoate pinul 1 din cupla electrica a senzorului de noxe
var 2. Se scoate pinul 10 din cupla electrica X3212. aceasta se afla in partea spate dreapta a motorului.

EURO6 AdBlue Emulators Disable System:

– AdxBlue system (Fully)
– AdxBlue NOX sensor
– DPF system
– DPF temperature sensors
– DPF regeneration

After installing Euro6 Emulator, you can remove:

– DPF sensors – YES
– NOx sensor – YES (only in DAF don’t remove first NOx sensor !!!)
– Adblue temp. sensor (s) – YES
– Adblue pump – YES
– Adblue level sensor – YES
– Adblue ECU – YES

Kindly note: It is possible to disable AdxBlue system by installing an AdxBlue emulator (programmable device) into the vehicle. You can switch it on/off anytime.

EURO6 AdBlue Emulators using guide:

Emulator Man Euro 6 does not need to be learned. You install emulator under the metal cover of AdBlue Pump on the right side behind the cab, and disconnect plug from AdBlue Pump and connect emulator.

Next, you need to remove the fuses:

F894(Multisensor In AdBlue tank)

F738 (+30 Signal of AdBlue pump)

F1084 (NOx sensor Upstream)

Fuse F737 is now fuse of emulator.

Fuse F1109 is the fuse of NOx sensor Downstream and A1191 mufler temperature sensor. This sensor needs to work correctly for DPF regeneration.

Finally, you need to remove Power from NOx downstream sensor. There are two ways options, one is to cut pin 1 in NOx sensor plug, the other way (better) is to remove pin 10 in X3212 plug. This plug is visible on rear of engine on the right side. This is TE plug (16 pin) with yellow key.

Package Includes:

1pc x Man EURO6 AdBlue Emulator

Alte detalii la suport tehnic.
